S/N
|
ITEM | DIMENSION | MAXIMUM TENSION | 20' FCL QTY | |||||||
| D1 | D2 | D4 | L1 | L2 | B | W | WEIGHT | ||||
| mm | mm | mm/inch | mm | mm | mm | mm | Kgs | MT | Pcs | ||
| 1 | 21X21(470A) | 535 | 200 | 152.4/6.0 | 530 | 470 | 159.5 | 19.6 | 34 | 125 | 220 |
| 2 | 21X21(470B) | 535 | 200 | 152.4/6.0 | 530 | 470 | 159.5 | 19.6 | 36 | 160 | 220 |
| 3 | 21X21(470C) | 535 | 230 | 152.4/6.0 | 540 | 470 | 159.5 | 19.6 | 42 | 260 | 220 |
| 4 | 21X21(480A) | 535 | 200 | 152.4/6.0 | 540 | 470 | 159.5 | 19.6 | 34 | 125 | 220 |
| 5 | 21X21(480B) | 535 | 200 | 152.4/6.0 | 540 | 470 | 159.5 | 19.6 | 36 | 160 | 220 |
| 6 | 30X21(A) | 762 | 260 | 152.4/6.0 | 540 | 470 | 159.5 | 19.6 | 72 | 230 | 156 |
| 7 | 30X21(B) | 762 | 300 | 152.4/6.0 | 540 | 470 | 159.5 | 19.6 | 85 | 300 | 156 |
| 8 | 30X21(C) | 762 | 300 | 152.4/6.0 | 540 | 470 | 159.5 | 19.6 | 96 | 450 | 156 |
| 9 | 30X42 | 762 | 300 | 152.4/6.0 | 1070 | 982 | 159.5 | 19.6 | 120 | 550 | 73 |
| 10 | 40x21(A) | 1016 | 300 | 152.4/6.0 | 545 | 470 | 159.5 | 19.6 | 135 | 300 | 96 |
| 11 | 40x21(B) | 1016 | 300 | 152.4/6.0 | 545 | 450 | 159.5 | 19.6 | 180 | 350 | 96 |
| 12 | 40x42 | 1016 | 300 | 152.4/6.0 | 1070 | 982 | 159.5 | 19.6 | 185 | 650 | 48 |
